[Space] update

[Mikolaj Habryn]

Excellent news :) How much did the battery go down during the drive?

On the camera front, while I'm in-zen-tune with CHDK, here's detailed
instructions for the A700 (which I'm going to forget by tomorrow):

Turn camera on.
Make sure the mode switch is set to record, not playback.
Observe some fields (including time) displayed in red text on blue
background in the top right corner - if they aren't there, CHDK isn't
loaded; make sure the SD card write protect switch is set (CHDK
overrides the write protection when saving images), start again from
top.
Press the print button (switches to CHDK command mode - hold it down
for a second or so to register)
The word 'Intervalometer' should appear at the bottom left (the active
script name) - if it doesn't, then press menu to bring up menus and
work out how to load the script (exercise for the student).
Having confirmed that Intervalometer is loaded:
  press the print button again to disable command mode
  press display repeatedly until the display turns off (led on top
will stay green)
  press print button for command mode
  press the shutter button once to start the script

At this point the LEDs next to the viewfinder should flash, the blue
led on the print button will light up, and you'll eventually hear a
shutter click. If the blue led doesn't light, the camera didn't
register the change into command mode - cycle the display on again and
retry. Otherwise, hang around for 30 seconds to make sure they do it
again. Install in payload.

We have the option of using a fisheye lens on the front. I kinda like
the effect artistically and it probably makes sense to get the extra
visual range at the cost of the corner pixels, but very open to
suggestions from anyone more knowledgeable and/or opinionated about
photography. Examples of each pointed in roughly the same direction
attached.

m.



On Sat, Feb 6, 2010 at 11:51 PM, Andrew Gerrand <andrewdg at gmail.com> wrote:
> An update from the Android team:
>
> Just did a test-drive with GPS running. We collected about 4200 GPS
> co-ordinates and a significantly larger number of
> accelerometer/temperature/magnetic readings. The unit seemed to
> perform perfectly, as far as I can tell.
>
> Please see attached for a KML file (readable in Google Earth). As you
> can see, we stopped at In-N-Out Burger on the way home. ;)
>
> It does appear that the GPS remains stuck-on after the application
> exits, but this is of little concern to us. I think it would be best
> if we plan to cold-boot the phone and start the applet as close to
> launch as possible. This would minimise the likelihood of the GPS unit
> going 'stale' (as rumoured) in a stationary position. Although this
> would require us to put the G1 somewhere easily accessible in the
> payload.
>
> FWIW about 1.2 hours of collected data works out to 11MB, so there's
> plenty of space on the card. (in fact, if you want to swap the 1gig
> back into the G1 and use the 8gig for a camera, please do)
>
> Great news on the cameras! Here's hoping for more good luck with APRS. =)
>
> Andrew
>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: IMG_0036.JPG
Type: image/jpeg
Size: 1100296 bytes
Desc: not available
URL: <http://lists.noisebridge.net/pipermail/space/attachments/20100207/8f89e91b/attachment-0008.jpe>
